pcb separator machine

Name: pcb separator machine
Brand: Dobeter

Part Number :

Part Name : pcb separator machine

Delivery lead time :　in stock

Payment : TT , PayPal, CreditCard, Western Union

MOQ : 1PCS

Description for pcb cutter

pcb cutter

Description :pcb cutter is used for automatically counting reel SMD and IC packaging components.It can count out an entire reel or a specific number of parts, the LCD screen will display the number of the components, it also can be equipped with barcode scanner and printer to make some report. Available tape pitch 2 ,4, 8, 12, ... .48, 52, 56mm, available tape width: 8, 12, 16,24, 32, 44, 56mm.

V-CUT PCB CUTTER / SEPARATOR

Specification and Features:

Max. Separation Width
PCB thickness
Feed rate
Blade material
Size
Power
Weight

200 mm
0.5~3 mm
200,300,400,500mm/s
Sweden HSS SKH-7
340*340*420 (L*W*H)
AC220V, 50HZ, 30W
30 kg

The accurately adjustable space between the blades is applicable to the circuit board of various V-CUT depths.

The steady and accurate separation can effectively avoid the cracks of welding spot and the circuit board.

PS-3000 PCB CUTTER / SEPARATOR

Specification and Features:

Max. Separation Width
PCB thickness
Feed rate
Blade material
Size
Power
Weight

200 mm
0.5~3 mm
200,300,400,500mm/s
Sweden HSS SKH-7
720*370*390 (L*W*H)
AC220V, 50HZ, 30W
60 kg

1.Minimize the internal stress generated when cutting the PCB board to avoid tin crack
2.The board is placed under the point of the knife. Push the hahndle , the knife split the board up.
3.The board is fixed when spliting. Only the knife moves to avoid the parts to be damaged by moving.
4.The distance between two knives can be adjusted accurately in case of tool wear or the irregular depth of the groove.
5.The machine applies to both thin and thick boards, easy for operating.

Specifications
1.maximum of board length: 200mm
2.board thickness        :0.4~3mm
3.speed of sending board : it depends
4.material of knife         :HSS
5.Volume                :580mm(L) ×380mm(W) ×250mm(H)
6.weight                 :15kg

pcb separator blade
