Type Part number Depth (mm) Feeding pitch (mm)

TOPAZ FEEDER

For Topaz, Topaz X, Topaz XII, Sapphire-Xii, MG1,MG2,EMERALD,EMERALD X, EMERALD X II,SAPPHIRE / COMET

8mm 01005 CL Tapefeeder 9498 396 02008 PA 2903-96
8mm feeder for 01005, 2mm pitch, Green Handle Yellow Band CL-822-15
2.5
2
8mm 0201 CL Tapefeeder Part nr.: 9498 396 00339 PA 2903-77
8mm feeder for 0201, 2mm pitch Green Handle CL-823-15

8mm 0402 CL Tapefeeder Part nr.: 9498 396 00340
Alternate Part Number: 9498 396 00498
PA2903-78
8 mm feeder for 0402, 2mm pitch, reel Blue Handle CL-825-15
2.5
2
8mm Standard CL Tapefeeder Part nr.: 9498 396 00341 PA 2903-79
8 mm feeder, STD, 4mm pitch, reel Black Handle CL-84-15
2.5
4
12mm CL Tapefeeder Part nr.: 9498 396 00342 PA 2903-88 12mm CL feeder, 4-12mm pitch, 15" Reel Holder Black Handle CL-12 2.5 4,8,12
16mm CL Tapefeeder Part nr.: 9498 396 00338 PA 2903-27
16mm feeder, 4-16mm pitch, 15" Reel Holder Black Handle CL-16
11 4,8,12,16
24mm CL Tapefeeder Part nr.: 9965 000 15825 PA 2903-38
24mm feeder, 4-24mm pitch, 15" Reel Holder CL-24
15
4,8,12,16,20,24
32mm CL Tapefeeder Part nr.: 9965 000 15826 PA 2903-48
32mm feeder, 8-32 mm pitch, 15" Reel Holder CL-32
15
4,8,12,16,20,24,28,32
TOPAZ FEEDER for Topaz, Topaz X, Topaz XII, Sapphire-Xii, MG1,MG2,EMERALD,EMERALD X, EMERALD X II,SAPPHIRE / COMET
44mm CL Tapefeeder Part nr.: 9965 000 15827 PA 2903-58
44mm feeder, 8-36 mm pitch, 15" Reel Holder CL-448
15
4,8,12,16,20,24,28,32,36
56mm CL Tapefeeder Part nr.: 9965 000 15828 PA 2903-68
56mm feeder, 8-36mm pitch, 15" Reel Holder CL-56
15
4,8,12,16,20,24,28,32,36
72MM CL Tapefeeder Part nr.: 9498 396 01977 PA 2903-67
72 6mm feeder, 8-36mm pitch, 15" Reel Holder CL-72
15 4,8,12,16,20,24,28,32,36
Topaz FEEDER for Topaz, Topaz X, Topaz XII, Sapphire-Xii, MG1,MG2,EMERALD,EMERALD X, EMERALD X II,SAPPHIRE / COMET
8mm 0402 CL Tapefeeder 8mm 0402 CL Tapefeeder Part nr.: 9498 396 00340 2903-78 8 mm feeder for 0402, 2mm pitch, reel Blue Handle CL-825-15
  Topaz Feeder Topaz Feeder Topaz Feeder
  Topaz Feeder Topaz Feeder Topaz Feeder
Topaz FEEDER for Topaz, Topaz X, Topaz XII, Sapphire-Xii, MG1,MG2,EMERALD,EMERALD X, EMERALD X II,SAPPHIRE / COMET
8mm Standard CL Tapefeeder 8mm Standard CL Tapefeeder Part nr.: 9498 396 00341 PA 2903-79 8 mm feeder, STD, 4mm pitch, reel Black Handle CL-84-15
  Topaz Feeder Topaz Feeder Topaz Feeder
  Topaz Feeder Topaz Feeder Topaz Feeder
Topaz FEEDER for Topaz, Topaz X, Topaz XII, Sapphire-Xii, MG1,MG2,EMERALD,EMERALD X, EMERALD X II,SAPPHIRE / COMET
8mm 0201 CL Tapefeeder
Part nr.: 9498 396 00339 PA 2903-77 8mm feeder for 0201, 2mm pitch Green Handle CL-823-15
12mm CL Tapefeeder
Part nr.: 9498 396 00342 PA 2903-88 12mm CL feeder, 4-12mm pitch, 15" Reel Holder Black Handle CL-12
  Topaz Feeder Topaz Feeder Topaz Feeder
  16mm CL Tapefeeder
Part nr.: 9498 396 00338 PA 2903-27 16mm feeder, 4-16mm pitch, 15" Reel Holder Black Handle CL-16
24mm CL Tape Feeder
Part nr.: 9965 000 15825 PA 2903-38 24mm feeder, 4-24mm pitch, 15" Reel Holder CL-24
32mm CL Tapefeeder
Part nr.: 9965 000 15826 PA 2903-48 32mm feeder, 8-32 mm pitch, 15" Reel Holder CL-32
  Topaz Feeder Topaz Feeder Topaz Feeder
  44mm CL Tapefeeder
Part nr.: 9965 000 15827 PA 2903-58 44mm feeder, 8-36 mm pitch, 15" Reel Holder CL-44
56mm CL Tapefeeder
Part nr.: 9965 000 15828 PA 2903-68 56mm feeder, 8-36mm pitch, 15" Reel Holder CL-56

72mm CLi Tapefeede
Part nr.: 9498 396 01977 PA 2903-67 72mm feeder, 8-36mm pitch, 15" Reel Holder CLi-72
  Topaz Feeder Topaz Feeder Topaz Feeder
  FS2 8*2 FS2 8*2 FT 8*2
  Topaz Feeder Topaz Feeder Topaz Feeder
  Topaz Feeder Loading Unit(Station )
  Topaz Feeder Loading Unit(Station )

TOPAZ FEEDER PARTS for Topaz, Topaz X, Topaz XII, Sapphire-Xii, MG1,MG2,EMERALD,EMERALD X, EMERALD X II,SAPPHIRE / COMET
TOPAZ STICK FEEDER for Topaz, Topaz X, Topaz XII, Sapphire-Xii, MG1,MG2,EMERALD,EMERALD X, EMERALD X II,SAPPHIRE / COMET
  ltage:24V/110V/220V Size:430*60*60 Applied to: Topaz ,MG ,EMERALD... Voltage:24V/110V/220V Size:430*100*60 Applied to: Topaz ,MG ,EMERALD... Voltage:24V/110V/220V Size:430*150*60 Applied to: Topaz ,MG ,EMERALD...
  Topaz STICK FEEDER Topaz STICK FEEDER Topaz STICK FEEDER
  Voltage:24V/110V/220V Size:430*100*60 Applied to: MC series
  Topaz STICK FEEDER
TOPAZ TRAY FEEDER for Topaz, Topaz X, Topaz XII, Sapphire-Xii, MG1,MG2,EMERALD,EMERALD X, EMERALD X II,SAPPHIRE / COMET
  Topaz Tray Feeder for MC Series Topaz Tray Feeder for Topaz Series
  Topaz Tray Feeder for MC Series Topaz Tray Feeder for Topaz Series
TOPAZ FEEDER STORAGE TROLLEY ,CART for Topaz, Topaz X, Topaz XII, Sapphire-Xii, MG1,MG2,EMERALD,EMERALD X, EMERALD X II,SAPPHIRE / COMET

Size:L800*W600*H1100
Description:40PCS/Layer,2 Layers
Applied to: Topaz

Size:L800*W600*H1100
Description:40PCS/Layer,2 Layers
Applied to: Topaz

Size:L800*W600*H1100
Description:40PCS/Layer,2 Layers
Applied to: Topaz MC Series

Topaz Feeder Storage racks Topaz Feeder Storage racks Topaz Feeder Storage racks
TOPAZ FEEDER CALIBRATION JIG for Topaz, Topaz X, Topaz XII, Sapphire-Xii, MG1,MG2,EMERALD,EMERALD X, EMERALD X II,SAPPHIRE / COMET
Intellectual Feeder Calibration Jig Topaz Feeder Calibration Jig Traditonal Feeder Calibration Jig, with X, Y, Z axises
Topaz feeder calibration jig Topaz feeder calibration jig Topaz feeder calibration jig
Through years of efforts, we've developed Philips Topaz GEM series SMT feeder(Topaz ,Emerld, Opal, Sapphire,) ,including
1. Topaz Feeder CL 8x2mm Feeder KW1-M1300-020
2.Topaz Feeder 08x02 Feeder PA2903/74
3.Topaz Feeder8mm Feeders PA2903/79
4.Topaz Feeder12mm Feeders PA2903/
5.Topaz Feeder16mm Feeders Variable Pitch
6.Topaz Feeder24mm Feeders PA2903/79
7.Topaz Feeder32mm Feeders PA2903/79
8.Topaz Feeder44mm Feeders PA2903/79
9.Topaz Feeder56mm Feeder
10.Topaz Feeder72mm Feeder
11. Philips CL 8x2mm Feeders for 0201 components
These products look not only in apperance but also in quality are quite the same as original ones.We also offer you all Philips feeder spare parts, such asTAPE GUIDE ASSY, BACK STOPPER,SPROCKET AXIS ASSY,MULTI CYLINDER,SPRING,KNOCK PIN,INDENTATION LVR ASSY,DRIVE ROLLER ASSY,IDLE ROLLER ASSY and so on.
